Triumph NTO-16, 16,000 lb 2 Post Lift

NTO-16 16,000 lb 2 Post Lift by Triumph

Sick of lifts that act like they’ve just been asked to bench press a truck? Enter the Triumph NTO-16—a 16,000 lb Two Post Auto Lift that eats heavy vehicles for breakfast. This isn't your run-of-the-mill garage equipment. The NTO-16 is ISO 9001 and CE Certified, which is fancy talk for "it’s built like a tank and isn't going to crumble under pressure." With direct drive cylinders and an automatic safety shut-off, it's like having a bodyguard for your cars—tough, reliable, and always on alert. It effortlessly lifts 16,000 lbs to a max height of 72 inches.

With a spacious 102" drive-through width and a lightning-quick 40-second lift time, it’s like the NTO-16 is saying, "Is that all you've got?" And with a one-year parts warranty and a five-year structural warranty, it’s sticking around for the long haul. Stop wrestling with wimpy lifts and get one that knows how to do its job. Order the Triumph NTO-15 today and give your shop a real powerhouse!

Triumph NTO16 Specifications:

• Lifting Capacity: 16,000 lbs

• Overall Height: 165"

• Overall Width: 142"

• Maximum Lifting Height: 72"

• Distance Between Posts: 116"

• Drive-Thru Width: 102"

• Lowered Height: 7"

• Base Plate Size: 20" × 20"

• Lift Time: 40 seconds

• Power Requirement: 220V

• Motor: 3 HP

• Concrete Requirements: Minimum of 6"-3000psi

• Style: Overhead

• Lock Release: Single-point

• Electric Safety Cutoff: Yes


• Hydraulic Fluid Requirement: AW32


• Pallet Dimensions: 144" x 36" x 48"  - 2,500 lbs.

NTO 16 16,000 lb 2 Post Lift Special Features:

• The NTO-16 has replaced the NTO-15 with some refinements in the lift structure and components.

• 16,000 lb lifting capacity for heavy-duty service

• Direct-drive cylinders for smooth, reliable operation

• Electrical override with automatic safety shut-off

• Fast 40-second lift time for improved workflow

• Free mounting hardware included

• Truck adapters included

• Warranty: 1-year parts warranty and 5-year structural warranty
